Overview:
True Unified NVMe Storage Solution for Scaling Applications
The Unity NV10000 product introduces All-Flash NVMe capabilities to the Unity platform, offering optimal performance, capacity and flexibility. This all flash NVMe solution boosts the Unity platform by providing bandwidths up to 20GB/s. This allows you to scale performance as your application needs evolve. This platform can be used as primary storage tier, or a FASTier cache acceleration layer. This solution also supports flexible configurations and is designed for simplified expansion providing for capacity and performance requirement.
Unity Enterprise-Class Storage is a True Unified Solution. Unity is a high availability multi-protocol (Block, File, and Object) solution designed specifically for enterprises. The Unity features flexible configurations and is designed for simplified expansion, providing for capacity and performance requirements. Unity delivers core enterprise features that are exactly what customers demand, in a single platform. Unity supports a comprehensive OS matrix and is certified as a Veeam Ready Repository
Security, Compliance and Ransomware Protection. Unity supports immutable block and file snapshots. This allows customers to create locked-down point-in-time copies of their data. The Unity Object Store also supports object locking, allowing customers to protect data by making it immutable.
The advanced Unity architecture seamlessly works with the Assureon® (as an Active Data Vault or as Unbreakable Backup™) to deliver an immutable data protection solution. Businesses have the ability to recover data or backups from security breaches such as ransomware attacks.
Unity Hybrid Storage Platform supports SAS HDDs and All-Flash SSDs for flexible deployment options depending on business needs.”
Features:
Enterprise NAS
Enterprise NAS (NFS, CIFS/SMB) for unstructured data and files.
High Performance Block
High performance block (FC, iSCSI) for structured data (databases and Exchange).
Object Storage
Supports object locking, enabling anti-ransomware, regulatory and compliance requirements.
All-Flash
High performance arrays make it easy and affordable to meet the needs of critical business applications.
FASTier
Accelerated RAM and flash caching for high performance.
Unbreakable Backup
Unity with Assureon delivers an immutable Unbreakable Backup™ for ransomware protection.
Security, Compliance and Ransomware Protection
Unity supports immutable snapshots of volumes and file systems. This enables the creation of locked- down point-in-time copies of data. The Unity S3 Object Store supports object locking, allowing customers to protect data by making it immutable. It also supports data life-cycle management policies, making it the ultimate storage solution for enterprise applications.
The advanced Unity architecture seamlessly works with the Assureon® active data vault and gives customers the peace of mind that their data is protected for regulatory compliance and from security breaches including ransomware. As malware is now also targeting backups, Unity with Assureon delivers an immutable Unbreakable Backup solution so you never have to worry about your ability to recover.
Feature-Rich, Enterprise-Ready
Unity delivers core enterprise features that are exactly what customers demand in a single platform for multi-protocol access along with advanced features like high availability, snapshots, ESXi integration, in-line compression, FASTierTM caching, asynchronous and synchronous replication, data at rest encryption, and storage pool scrubbing to protect against bit rot, avoiding silent data corruption. Unity supports a comprehensive OS matrix and is certified as a Veeam Ready Repository.
True Unified Solution
Unity supports block (iSCSI, FC), file (NFS, SMB) and object (S3) protocols that can adapt to any storage environment. Unity is deployed in financial institutions, multimedia production companies, hospitals, national labs for multiple applications. These include big data, backup/archive, data virtualization, databases, database dumps and log files, file sharing, video editing and more.
All-Flash NVMe Configurations
The Nexsan Unity all-flash, high performance arrays make it easy and affordable to meet the needs of critical business applications. The system supports 368TB of raw NVMe all-flash capacity, and can also serve as a FASTier cache for up to 8.64PB of data capacity
Unity Makes Storage Easier with Data Migration and Cloud Connector
The optional add-on software provides data migration capabilities that make implementation even easier by replicating files from any legacy system. It also connects to numerous public clouds including Amazon S3, Google Cloud and Microsoft Azure, allowing organizations to move data as needed for tiered storage and optimizing hybrid cloud infrastructures.
Specifications:
| Category | Feature | Unity NV10000 |
|---|---|---|
| Enterprise Features | ||
| Security, Compliance and Ransomware Protection | Unity includes support for immutable volume and file system snapshots, S3 object locking and integrates with Assureon active data vault allowing enterprises to address a wide variety of data protection use cases. | |
| Supports Multiple Protocols* | SAN (Fibre Channel, iSCSI), NAS (NFS, CIFS, SMB 1.0 to 3.0, FTP), Object (S3) | |
| Unbreakable Backup | When utilizing Unity plus the optional Assureon for backups, the immutable backup solution protects from ransomware attacks and can be implemented in various configurations including tiered, replicated and high availability. | |
| Flexible Configurations | Unity is optimized to deliver the performance you need whether it’s a hybrid configuration or an allflash, making it easy and affordable to meet the application needs. | |
| Data Migration and Cloud Connector | This optional functionality includes a cloud connector to numerous public clouds including Amazon S3, Google Cloud and Microsoft Azure. The migration utility is utilized to seamlessly migrate data to Unity | |
| User Interface | Unity includes both a built-in HTML5-based UI and a comprehensive Command Line Interface (CLI). The Unity UI allows an administrator to easily manage and monitor a Unity deployment, regardless of size, from anywhere with just a web browser. | |
| PCI Compliance | Unity supports TLS 1.2 for PCI compliance | |
| Authentication | Active Directory, LDAP, and Local | |
| Host Platforms | All major platforms including Windows, Linux, Mac, VMware ESX, Hyper-V, Xen | |
| Data Services | Advanced data reduction, thin provisioning with dead space reclamation, replication, and snapshots | |
| Performance | Up to 20 GB/s | |
| 3rd Party Software Supported | Windows VSS, VMware VAAI, Commvault, Veeam Ready Repository & More | |
| High Availability | No single point-of-failure architecture with dual redundant storage controllers, redundant power supplies and RAID. | |
| System Configuration | ||
| Disk bays | # JBODs Supported | 24 | up to 8*** | |
| Form Factor | 2U | |
| System Memory/DRAM | Up to 192GB per Controller | |
| Supported Expansion Systems | US224** | U2G460** | E-Series for SED & QLC - See E-Series Data/Spec Sheet | |
| Controllers | 2 | |
| Storage Media | ||
| 2.5” NVME 1DWPD SSDs (TB) | 1.92 | 3.84 | 7.68 | 15.36 | |
| Self-Encrypting Drives (SED) and QLC Flash Supported | Requires E-Series Expansions - See E-Series Data/Spec Sheet | |
| Maximum Drives with Expansion HDDs | SSDs | 480 | 216 | |
| Self-Encrypting Drives (SED) and QLC Supported Chassis | ||
| Number of Chassis Supported | 6: 2 E-Series Head Unit + 4 Expansions | |
| 3.5” 7.2K Drives (TB) | 4 | 6 | 10 | 12 | 14 | 16 | 18 | 20 | |
| SED E-Series Chassis Supported | All E-Series and BEAST Products | |
| Maximum Raw Capacity with SED | Rack U | Up to 7.2PB | 26U | |
| 2.5” QLC Flash Drives (TB) | 1.92 | 3.84 | 7.68 | |
| QLC E-Series Chassis Supported | E18F (2U) | E32F (2U) + Expansions | |
| Maximum Raw Capacity with QLC | Rack U | 2.33PB | 22U | |
| Host Connectivity | ||
| 8Gb/s Fibre Channel Max Number of Ports/System | 8 using dual port cards | |
| 16Gb/s Fibre Channel Max Ports | 8 | 16 with dual port | |
| 32Gb/s Fibre Channel Max Ports | 8 with dual port | |
| 100GbE Max Number of Ports/System | 2 | |
| 40GbE Max Number of Ports/System | 4 | |
| 25GbE Max Number of Ports/System | 4 | |
| 10GbE Max Number of Ports/System | 12 | |
| 1GbE Max Number of Ports/System | 16 | |
| 10GbE Embedded Standard Configuration | Yes | |
| System Storage Services | ||
| Max NFS File Systems | 512 | |
| Max CIFS File Systems | 512 | |
| Max Snapshots per File System/LUN | 2048 | |
| Max LUNs per Target | 255 | |
| Max LUN Size | 256TB | |
| System Max LUNs | 255 - Fibre Channel* | 1024 - iSCSI | |
| Max Snapshots per LUN | 2048 | |
| Replication | Synchronous and asynchronous per storage pool, LUN and file system | |
| Power, Cooling, & Environmental | ||
| Number of hot-swappable power supplies - head units | 2 | |
| Voltage, Frequency | 100-240V | 50-60Hz | |
| Operating Temperature | 10-35C, 50-95F | |
| Operating Humidity | 20-95% (non-condensing) | |
| Wattage per Controller | 1200W | |
| Maximum Power/Controller Node | 1200W | |
| Size & Weight | ||
| Controller Form Factor | 2U | |
| Dimension (WxHxD) | 17.2 x 3.5 x 26.75 in | 437 x 89 x 679 mm | |
| Controller Unit Weight | 85 lbs. (38.6 kg.) | 90 lbs. (40.8 kg.) | |
| Rails & Cables | ||
| Mounting Rails and SAS Cables included | Yes | |
| Power Cable | ||
| Power Cable | 5-15 & C13/C14 | |
| SAS Storage Chassis for Expansion | ||
| 12Gb/s SAS Standard Configuration (per controller) # of SAS Ports | 4 | |
| 12Gb/s SAS Standard Configuration | PCIe Card Type (per controller) | Quad Port | |
| Storage Chassis Supported | Front Bay | US224*| U2G460**| E-Series for SED or QLC - See E-Series Data/Spec Sheet |
Documentation:
Download the Nexsan Unity NV10000 Datasheet (PDF)
